3 stage High Pressure Oil Free Nitrogen Piston Compressor

Short Description:


  • Brand: Huayan Gas
  • Place of Origin: China·Xuzhou
  • Compressor structure: Piston Compressor
  • Model: ZW-0.6/2-25 (customized)
  • Volume flow: 3NM3/hour~1000NM3/hour (customized)
  • Voltage: : 380V/50Hz (customized)
  • Maximum outlet pressure: 100MPa (customized)
  • Motor power: 2.2KW~30KW (customized)
  • Noise: <80dB
  • Crankshaft speed: 350~420 rpm/min
  • Advantages: high design exhaust pressure, no pollution to compressed gas, good sealing performance, corrosion resistance of optional materials.
  • Certificate: ISO9001, CE certificate, etc.
  • Product Detail

    Product Tags

    NITROGEN PISTON COMPRESSOR-REFERENCE PICTURE

    2016120635495165

    PRODUCT DESCRIPTION

    The gas compressor is suitable for a variety of gas pressurization, transportation and other working conditions. Suitable for medical, industrial, flammable and explosive, corrosive and toxic gases.

    Nitrogen compressor is our company's main product, with mature technology and high stability. Mainly include large and medium-sized natural gas compressors. The discharge pressure ranges from 0.1MPa to 25.0MPa, and the displacement ranges from 0.05m3/min to 20m3/min. The compressors are available in Z-type, D-type, V-type, W-type and other forms for users to choose, as well as explosion-proof nitrogen compressors. For users to choose.

    ◎Characteristics: The whole machine has the characteristics of long service life, sufficient air volume and convenient maintenance.

    ◎Scope of application: Widely used in nitrogen pressurization at the back end of nitrogen generators, nitrogen replacement in chemical plants and gas units, as well as nitrogen filling bottles, nitrogen injection wells, etc.

    A. Classified by structure:
    Piston compressors have four main types: Z, W, D, etc.;
    B. Classified by compressed media:
    It can compress rare and precious gases, flammable and explosive gases, etc.
    C. Classified by sports organization:
    Crankshaft connecting rod, crank slider, etc.;
    D. Classified by cooling method:
    Water cooling, oil cooling, rear air cooling, natural cooling, etc.;
    E. Classified by lubrication method:
    Pressure lubrication, splash lubrication, external forced lubrication, etc.

    IMG_20180525_172821
    IMG_20180507_103413

    NITROGEN PISTON COMPRESSOR-PARAMETER TABLE

    Partial Nitrogen Piston Compressor Product Specifications



    Model

    Flow-rate

    (Nm³/h)

    Intake pressure

    (MPa)

    Exhaust pressure

    (MPa)

    Rotating speed

    (Rpm)

    Motor Power

    (Kw)

    1

    ZW-0.6/2-25

    90

    0.2

    2.5

    740

    30

    2

    ZW-1.5/1-12

    180

    0.1

    1.2

    730

    22

    3

    ZW-1.4/2-40

    250

    0.2

    4

    740

    37

    4

    ZW-1.3/4-25

    340

    0.4

    2.5

    980

    37

    5

    VW-7.2/2.5-6

    1200

    0.25

    0.6

    980

    45

    6

    VW-15/0.5-3

    1200

    0.05

    0.3

    980

    75

    7

    VW-9.7/1-10

    1100

    0.1

    1.0

    985

    110

    8

    VW-7.2/1-22

    800

    0.1

    2.2

    985

    132

    9

    DW-1.2/2-150

    400

    0.2

    15

    740

    45

    10

    DW-0.5/20-160

    600

    2.0

    16

    740

    75

    11

    DW-3.8/10-45

    2300

    1.0

    4.5

    740

    185

    12

    DW-11/4-20

    3000

    0.4

    2.0

    740

    250



    SUBMIT INQUIRY PARAMETERS

    If you want us to provide you with detailed technical design and quotation, please provide the following technical parameters, and we will reply to your email or phone within 24 hours.

    1.Flow: _____ Nm3 / hour

    2.Inlet pressure: _____Bar(MPa)

    3.Outlet pressure: _____Bar(MPa)

    4. Gas medium: _____

    We can customize a variety of compressors. Please send the above parameters to email: Mail@huayanmail.com
